Sui Mainnet Halt of May 28, 2026: An Address Balance Gas Underflow Post-Mortem

The two tweets above bracket the entire public picture of the May 28, 2026 Sui mainnet incident. Behind them is a single sharply-scoped bug at the seam of two new features — Address Balance and coin reservations — that allowed a perfectly ordinary user-submitted transaction to plant a poisoned AccumulatorEvent into a checkpoint, causing the per-checkpoint settlement system transaction to abort and every honest validator to stall at the same block.

The fix landed as an out-of-band emergency patch to releases/sui-v1.72.0, and was forward-ported to main as commit 124c64e ("Land #26816 gas-underflow fix in main (#26828)"). The forward port touches just two files: a 16-line change to execution_engine.rs and a regression test in address_balance_compatibility_tests.rs. The brevity of the fix is itself a useful data point: the underlying invariant was simple, and the bug was a missing case, not a structural problem.

This post walks the bug end-to-end: why a failed transaction could emit settlement-impacting side effects, why the existing safety net did not catch this shape, what exactly the patch does, and what the incident says about layering side-effects in a system that defers state changes to a separate Move-executed system transaction.

If you want to read the actual source while going through this post, pin this ref — git commit: 818f8d78f222b9279cb966a5754fb0a2c21d58b1.

TL;DR

A transaction that the adapter was already going to fail with InsufficientFundsForWithdraw (IFFW) still ran the gas smashing step before being aborted. Gas smashing for an Address Balance coin-reservation entry emits an accumulator Split event for the reservation amount. That Split was then handed to the per-checkpoint accumulator settlement system transaction, which calls sui::accumulator_settlement::settle_u128, which calls U128.update(merge, split):

public(package) fun update_u128(u128: &mut U128, merge: u128, split: u128) {
    u128.value = u128.value + merge - split;
}

With the Address Balance already drained to 0, merge == 0 and split > 0, so Move's checked arithmetic underflowed and aborted the settlement transaction. Because settlement is a *system* transaction whose contents are deterministically derived from the checkpoint, every honest node hit the same abort at the same checkpoint — and mainnet stalled.

The fix removes Address Balance reservation entries from gas_data.payment whenever execution is going to early-abort with InsufficientFundsForWithdraw, so smashing never runs over them and the bad Split is never produced in the first place.

Background

Address Balance and accumulators

Address Balance is Sui's account-style balance model layered on top of its object model. Rather than holding SUI exclusively as discrete Coin objects, a user can hold a balance at the address level. On-chain, that balance lives under a single shared AccumulatorRoot object as a dynamic field whose value is a U128:

public struct U128 has store {
    value: u128,
}

Crucially, user transactions do not mutate that field directly. Doing so would serialize every transaction in the network on the shared AccumulatorRoot. Instead, user transactions emit AccumulatorEvents — Merge for a deposit, Split for a withdrawal — and the actual mutation is deferred to a per-checkpoint system transaction that aggregates all events and applies the net change. This indirection is what keeps Address Balance compatible with Sui's parallel execution model.

The settlement system transaction

After a checkpoint's user transactions are executed, the validator builds a settlement transaction from their AccumulatorEvents. The aggregation logic walks every transaction's effects, sums Merge and Split separately per (accumulator_obj), and then emits a Move call for each updated accumulator:

builder.programmable_move_call(
    SUI_FRAMEWORK_PACKAGE_ID,
    ACCUMULATOR_SETTLEMENT_MODULE.into(),
    ACCUMULATOR_ROOT_SETTLE_U128_FUNC.into(),
    vec![address.ty.clone()],
    vec![root, address_arg, merge_amount, split_amount],
);

The builder packages these calls as a TransactionKind::ProgrammableSystemTransaction, and the execution engine dispatches that variant into the PTB executor with the Move VM:

TransactionKind::ProgrammableSystemTransaction(pt) => {
    SPT::execute::<execution_mode::System<Mode::Error>>(
        protocol_config, metrics, move_vm, temporary_store, ...
        gas_charger, None, pt, trace_builder_opt,
    )
}

This is the critical layering: all accumulator state changes go through Move. Rust orchestrates which calls to make, but the calls themselves run inside the Move VM and are bound by Move's checked arithmetic and assert! semantics. The Move callee in accumulator_settlement.move is the only code authorized to write the accumulator value:

fun settle_u128<T>(
    accumulator_root: &mut AccumulatorRoot,
    owner: address,
    merge: u128,
    split: u128,
    ctx: &TxContext,
) {
    assert!(ctx.sender() == @0x0, ENotSystemAddress);
    assert!((merge == 0) != (split == 0), EInvalidSplitAmount);

    let name = accumulator_key<T>(owner);
    if (accumulator_root.has_accumulator<T, U128>(name)) {
        let is_zero = {
            let value: &mut U128 = accumulator_root.borrow_accumulator_mut(name);
            value.update(merge, split);
            value.is_zero()
        };
        if (is_zero) { ... }
    } else {
        assert!(split == 0, EInvalidSplitAmount);
        ...
    };
}

And the actual arithmetic, in accumulator.move:

public(package) fun update_u128(u128: &mut U128, merge: u128, split: u128) {
    u128.value = u128.value + merge - split;
}

Move's integer arithmetic is checked. Any expression where split > value + merge aborts the call — and since the call is the body of the settlement system transaction, the abort bubbles up to abort the whole system transaction.

Coin reservations and gas smashing

Sui has long supported paying gas from a list of coin objects, "smashing" them together: the first coin in the list becomes the primary, the others have their balances folded into it, and the others are deleted. With Address Balance, that mechanism was extended so that a gas-payment entry can be a coin reservation — a synthetic ObjectRef whose digest, when decoded with ParsedDigest::try_from, represents "treat this entry as a reservation_amount() withdrawal from the owner's address balance" rather than as a real coin object. The classification is in execution_engine.rs:

if let Ok(parsed) = ParsedDigest::try_from(entry.2) {
    PaymentMethod::AddressBalance(gas_data.owner, parsed.reservation_amount())
} else {
    PaymentMethod::Coin(*entry)
}

Smashing for a PaymentMethod::AddressBalance cannot delete an object — there is no object — so instead it emits a negative-balance AccumulatorEvent (a Split) for the reservation amount:

PaymentMethod::AddressBalance(sui_address, reservation) => {
    let event = AccumulatorEvent::from_balance_change(
        *sui_address,
        balance_type,
        i64::try_from(*reservation).unwrap().checked_neg().unwrap(),
    ).expect("...");
    temporary_store.add_accumulator_event(event);
}

That event is exactly the kind of event that the settlement aggregator later sums into a split value passed to settle_u128. Everything is wired correctly — *for a transaction that actually runs*.

The existing IFFW guard and why it did not catch this

Sui already has an IFFW guard, in gas_charger.rs:

if execution_result.as_ref().err().map(|err| matches!(
        err.kind(),
        sui_types::execution_status::ExecutionErrorKind::InsufficientFundsForWithdraw
    )).unwrap_or(false)
    && matches!(gas_payment_location, Some(PaymentLocation::AddressBalance(_)))
{
    return GasCostSummary::default();
}

This guard does two things: it triggers only when the final gas charge location (after smashing) is Address Balance, and it short-circuits the gas charge itself. It is about *not double-charging the AB when the AB withdrawal failed*. It says nothing about the Split events that smashing emitted for the non-primary entries before this guard runs. That is the seam the bug slipped through.

Root cause

Two preconditions had to line up:

• The transaction had to be admitted at signing/certificate-check time. Pre-execution checks validate a coin reservation against the AB observed at signing time. If the sender's AB is 20M and the reservation is 10M, the check passes.
• By the time the transaction actually executes, another transaction had to have drained the AB to 0. In the regression test, this is achieved by submitting both transactions in a single soft bundle so the executor processes them in order in the same batch.

Given those, the adapter sees an insufficient AB during execution, sets execution_params = Err(InsufficientFundsForWithdraw), and routes through the early-abort branch in execution_engine.rs so that no PTB body runs.

The problem: GasCharger::new runs before that abort branch is reached. Its constructor calls payment_kind(&gas_data, ...) → PaymentKind::smash(...) → SmashMetadata::smash_gas(...), and that smashing pass walks every entry in gas_data.payment. For any coin-reservation entry it writes an AccumulatorEvent::Split into the TemporaryStore. Those events are part of the transaction's effects, even though the transaction itself is going to fail.

Concretely, with a gas_data.payment of [real_coin_a, real_coin_b, coin_reservation(R)]:

• The smash target is real_coin_a (a real coin), so gas_payment_location is Coin, not AddressBalance. The existing IFFW guard quoted above never fires.
• During smashing, real_coin_b is folded into real_coin_a and deleted. coin_reservation(R) is converted into a Split event of R against the sender's Balance accumulator.
• Execution then aborts with InsufficientFundsForWithdraw. Object writes are reset, but the accumulator event from smashing is already in the effects.

Checkpoint settlement now aggregates this transaction's effects. The sender's Balance accumulator picks up merge = 0, split = R. The settlement transaction calls settle_u128, which after netting calls U128.update(0, R):

u128.value = 0 + 0 - R;  // checked underflow → abort

Move aborts the settlement system transaction. Because system transaction digests are derived deterministically from the checkpoint, every honest validator and full-node trying to apply that checkpoint hits the exact same abort. Settlement does not progress. Checkpoint application does not progress. Mainnet halts.

This is precisely the picture the second tweet describes: "a crash bug in the gas charging logic introduced by the 1.72 release." The 1.72 release introduced the Address Balance / coin-reservation gas-payment plumbing; the bug is a missing case in that plumbing for the IFFW early-abort path.

Impact

The impact is liveness, not solvency. Concretely:

• No funds were stolen and no balance was silently moved. Move's checked arithmetic refused the underflow. The settlement transaction aborted *instead of* applying a bad update. The accumulator state on disk was never corrupted.
• The chain stalled at the offending checkpoint. Validators and full-nodes could not produce/apply the settlement transaction for that checkpoint, so the chain could not advance past it. End users observed transactions being "paused" as the first tweet described.
• The condition was reachable by a non-privileged user. Constructing the trigger required only the ability to fund an Address Balance and submit a soft bundle of two transactions with a particular gas-payment shape. Nothing here required validator keys, admin privileges, or unusual protocol-level access.
• Resolution required a binary patch. Because settlement transactions are deterministically derived from checkpoint contents and execution-layer logic, the only path forward was to deploy the patched adapter on every validator. The second tweet's "Activity on Sui mainnet has resumed" corresponds to the cluster being upgraded to the patched binary.

The fix

The diff in execution_engine.rs changes gas_data from GasData to mut GasData in execute_transaction_to_effects and inserts this prune step before GasCharger::new:

// On an IFFW abort, drop the address-balance gas payments (keeping real coins) so the
// pruned list flows into `payment_kind`/`compute_input_reservations` with no special
// handling.
if matches!(
    execution_params,
    Err(ExecutionErrorKind::InsufficientFundsForWithdraw)
) && gas_data.payment.len() > 1
    && ParsedDigest::try_from(gas_data.payment[0].2).is_err()
{
    gas_data
        .payment
        .retain(|entry| ParsedDigest::try_from(entry.2).is_err());
}

Three things are worth highlighting about this patch:

Where the cut happens. The pruning runs before payment_kind and before compute_input_reservations. Both functions iterate gas_data.payment and classify reservation entries. By removing reservations upstream, the rest of the pipeline — payment_kind, gas smashing, input-reservation accounting, the final IFFW guard in gas_charger.rs — does not need any new IFFW-aware branches. There is exactly one decision point for this whole class of bug.

What is kept vs. dropped. Only coin-reservation entries (those whose digest *does* decode via ParsedDigest::try_from) are dropped. Real coin entries (where ParsedDigest::try_from(...).is_err()) are retained. The failing transaction therefore still has a valid gas-payment list and goes through normal gas charging, storage rebates, and effect generation. The user still pays for the failed attempt; only the spurious Split events disappear.

The two preconditions. The condition gas_data.payment.len() > 1 && ParsedDigest::try_from(gas_data.payment[0].2).is_err() matches exactly the dangerous shape: more than one payment entry, and the smash target is a real coin (so the existing IFFW guard in gas_charger.rs does *not* fire). If gas is paid purely from AB (smash target is itself a reservation), the older guard already short-circuits gas charging. If there is only one payment entry, there is nothing to smash.

This is the right call for an execution-layer change. Effects determinism is non-negotiable: replaying a historical checkpoint must produce byte-identical effects. Any change that alters the contents of gas_data mid-execution must be gated by protocol version so that pre-fix checkpoints replay the pre-fix behavior. The unconditional patch landed first because the bug was already taking down mainnet; the determinism-preserving gating ships in a clean follow-up.

The regression test

The regression test address_balance_compatibility_tests.rs is the minimal reproducer, and its comments are unusually blunt about the impact:

• Enable coin reservations via a protocol-config override; build a test cluster.
• Fund the sender's AB with initial_ab = 20_000_000. Per-tx reservations must be ≤ initial_ab to pass signing validation.
• TX1: pay gas from a real coin and withdraw the full initial_ab from AB to a dummy address. Succeeds and leaves AB at 0.
• TX2: gas_data.payment = [real_coin_a, real_coin_b, coin_reservation(initial_ab / 2)]. The reservation is structurally legal (≤ initial_ab), but the AB is 0 by the time TX2 runs. Two real coins are deliberately included so smashing would normally delete real_coin_b; the test transitively asserts (via SUI conservation) that this does not happen.
• Both transactions are submitted in sign_and_execute_txns_in_soft_bundle so the executor processes them in order in a single batch.
• The test asserts TX1 succeeds, TX2 fails with InsufficientFundsForWithdraw, and then calls wait_for_tx_settlement(&[tx1_digest, tx2_digest]). The wait is the actual failure surface — without the fix, settlement aborts.

The final assertion assert_eq!(final_ab, 0) confirms that the failed TX2 did not touch the AB either way.

Lessons

A few things make this incident more interesting than just "we forgot a case."

Side effects of failed transactions are first-class state. It is easy to assume that "the transaction failed" means "nothing in the temporary store matters." That is approximately true for object writes (the gas charger calls reset on error) and almost true for gas charging itself (Sui resets and re-smashes on certain failure paths). But AccumulatorEvents created during smashing are part of effects and survive into checkpoint settlement. Any feature that adds new side-effect channels needs to audit *every* early-abort path. The fix is small precisely because the design — events emitted by smashing, applied later by a system transaction — was sound. The bug was a single missing case in the early-abort path.

Reservations are not objects, and that matters. A real gas coin can be smashed, mutated, deleted — operations that are reversible within a single tx's TemporaryStore. A coin reservation is a *promise* to withdraw from an accumulator that lives outside the transaction's owned-object set; it is materialized as an event that *another* (system) transaction will consume. Once that event is in the effects, only the settlement code can decide what to do about it — and the settlement code has no concept of "this came from a failed transaction." The right place to suppress it is at the source.

Key Takeaways

References

• Incident tweets: stall announcement, resumption announcement
• Forward-port commit to main: 124c64e ("Land #26816 gas-underflow fix in main (#26828)")
• Original emergency fix: PR #26816 against releases/sui-v1.72.0
